Specifications
3 pulling rollers with independent hydraulic motors
• 60 mm shafts
•Roller diam. 200 mm
• Shafts supported on opposed taper roller bearing
• Hydraulic pressure roller adjustment
• Pressure roller digital control with heating settings options
• Cylinder thrust: 12 tons
• Shaft revolution speed: 13 RPM
• Controller motor power: 4 KW
• Vertical working height: mm 900
• Horizontal working height: mm 800
• Distance between centres: mm 300
• Pressure roller stroke mm 135
L 800 mm – W 1150 mm – H 1600 mm Weight 850 Kg
